Mono Solar Panel Solar LED Street Light With Ra>80 150lm/W Luminous Flux

Basic Information

Place of Origin:	Guangdong China
Brand Name:	Yahua Solar Street lighting
Certification:	CE IP65 ROHS ISO
Document:	Product Brochure PDF

Packaging Details:	Anti-collision and shatterproof packaging
Delivery Time:	5-8 days
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	500 pcs/month

Get Best Price Contact Now

Detail Information

Lighting Mode:	Remote Control+Light Control+Radar Sensor	CRI:	Ra>80
Warranty:	5 Years	Battery:	Lithium Iron Phoshpate Battery
Application:	Road , Street , Yard, Park, Garden Etc	IP Rating:	IP65 Waterproof
Material:	Aluminum Alloy	Luminous Flux:	150lm/w
Highlight:	150lm/W Integrated LED Solar Street Light , Mono Solar Panel Solar Street Lamp , CRI Ra 80 Solar Street Light

Product Description

Factory directly 80w with pole outdoor integrated all in one solar led street light

Character and application

Patented products, easy to install. The power supply box is made of die-casting aluminum alloy, which makes drivers have good heat dissipation,and improves the life of the product. This lamp is suitable for installation at 8-10 m height.

PRODUCT SPECIFICATIONS

Model	YHZ-SSL80W
Solar panel Max power	18V 120W (high efficiency imported silicon solar cell)
Solar panel Life time	25 years
Battery Type	12V 60Ah lithium battery(Life time 5 years)
LED Max power	12V 80W
Led chip brand	Bridgelux from USA with high brightness
Lumen (LM)	12000lm
LED Life time	50000hours
Lighting Viewing Angle	120°
Charge time(by sun)	6-8 hours (with enough strong shine)
Discharge time	>12 hours with full power; >40 hours with saving mode
Working TEMP( ℃ )	-20~+60
CCT (k)	6000k-6500k
Mounting height(m)	9-12m
Space between light(m)	25-30m
Lamps material of main	aluminium alloy
Certificate	ISO/CE/ROHS/IP65/IEC
Warranty years	3 years
Product weight	26KG
Carton size	125052860mm
Q'ty/ctn	1 carton for one lamp, 1 carton for one bracket
GW.for carton	27KG
20GP container	200Sets
40GP container	416Sets
