| Place of Origin: | China |
|---|---|
| Brand Name: | Yahua lighting |
| Certification: | CE, RoHS, IP65, ISO9001 |
| Model Number: | YHZ-HBL |
| Document: | Product Brochure PDF |
| Minimum Order Quantity: | 1 |
| Price: | USD19-49 |
| Packaging Details: | Foam + carton plus + wooden case |
| Delivery Time: | 3-7days |
| Payment Terms: | T/T, Wester union, Paypal, Credit Card |
| Supply Ability: | 8000PCS/Month |
| Working Temperature(℃): | -30-60 | Material: | Aluminum |
|---|---|---|---|
| Color: | White/Dark/Grey | Power: | 60W, 100W, 150w, 200w, 250w, 300w, 400w Avaliable |
| Luminous Flux: | 140-150lm/w | Light Source: | LED Brand Chips |
| IP Rating: | IP65/IP66 | Lifespan: | 50,000hrs |
| Highlight: | 300w LED Warehouse Lighting,150lm/w LED Warehouse Lighting,200w LED Warehouse Lighting |
||





| Product Code | YH-HBUFO-100W | YH-HBUFO-150W | YH-HBUFO-200W |
| LED Quantity | 160PCS 3030(2835) | 240PCS 3030(2835) | 320PCS 3030(2835) |
| Rate Power | 100W | 150W | 200W |
| Color Temperature | 6500/4000/3000k | 6500/4000/3000k | 6500/4000/3000k |
| Luminous Flux | 150LM/W | 150LM/W | 150LM/W |
| PF | >0.92 | >0.92 | >0.92 |
| Input Voltage | AC120-277V | AC120-277V | AC120-277V |
| Frequency Range | 50/60Hz | 50/60Hz | 50/60Hz |
| CRI | Ra75 | Ra75 | Ra75 |
| Temperature of working condition | (-40℃-50℃) | (-40℃-50℃) | (-40℃-50℃) |
| humidity of working condition | 20%-90% | 20%-90% | 20%-90% |
| LED life time | 50000h | 50000h | 50000h |
| Protestion Grade | IP66 | IP66 | IP66 |
| Product Size | Φ238*104.7mm | Φ298*149.1mm | Φ350*157.7mm |
| Packing Size | 285*285*140mm | 345*345*170mm | 400*400*190mm |
